Products Overview
This connector turns pins side ways. It sets on board face. Contacts use metal blend. Case bears heat. Users take it for edge spots. Single row stays narrow. SMT method glues flat. It works in level builds. We build unique ones. Choices add tin cover for slow rust. All obey RoHS. Check us for rules in zones.
Product Specification
|
PieceNote |
Power Peak3A, matches low draws in sets |
|
Block Pull |
Over 1000MΩ, cuts shorts in wet zones |
|
Volt Keep |
500V AC, from basic runs |
|
Touch Pull |
Below 20mΩ, smooths pass |
|
Warm Reach |
-40°C to +105°C; some top higher but view yours |
|
Cover Form |
Tin base; gold for strong hold |
|
Make Pieces |
Metal contacts; UL94 V-0 case for burn stop |
|
Space Length |
2.54mm gap, single row for side bends |
Products Points
This connector angles pins out. It aids side board links. SMT quickens make lines. Posts fix spot true. Break style lets snap fits. Caps ease pick up. Low shape trims room. It stands pulls in moves. We alter counts. Think it as a corner join for paths.
Products Roles
This serves sets. Edges need it for bends. Tools use it in frames. Lights gain from angle ties. Control gear fits well. Home items handle it. Test parts rely on it. Wire spots use near kinds.
Add a piece on make. Contacts use metal for flow. Case blocks fire. Safe tag halts spread. Space is 2.54mm. Outlines on need. Pin sums shift. Bend height like 2.5mm is standard but scan yours.We go by RoHS for pure build. Case owns UL94 V-0.
Advantages
● According to the market demand, the product is continuously developed
● Perfect quality control from materials to finished products.
● Traceability of Order and raw material
● Systematic lab testing ability
● Various transporation method
Shenzhen Xuhuasheng Technology Co., Ltd.(XHS) has been devoted to the production and sale of electronic connectors for 10 years, adhering to the belief of quality first and customer first. We are a reliable manufacturer in male header pins arduino connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in male header pins arduino connectors, welcome you to contact us. Just call or send email to us to get professional support, believe that XHS will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
Q: Do you have a product testing facility?
A: Yes, XHS has professional lab to test the materials and products.
Q: Do you have any distributors in my country?
A: No, we sell products from our factory in China directly, the transit period is 1-2 weeks.
Q: What are the environmental requirements for board-to-board connectors?
A: Some general environmental requirements to consider when selecting board-to-board connectors include:
1)Temperature range: The connector should be able to operate in the temperature range required for the specific application. This may include extreme temperature ranges, such as those found in industrial or automotive applications.
2)Moisture and humidity resistance: The connector should be resistant to moisture and humidity, which can cause corrosion and reduce the lifespan of the connector.
3)Chemical resistance: The connector should be able to resist exposure to chemicals that may be present in the environment, such as oils, solvents, and cleaning agents.
4)Vibration and shock resistance: The connector should be able to withstand mechanical stresses, such as vibrations and shocks, that may occur during operation.
5)Electromagnetic interference (EMI) shielding: The connector may need to provide EMI shielding to prevent interference with other electronic components.
6)Durability: The connector should be able to withstand repeated use and insertion/removal cycles without becoming damaged or degraded.
7)Size and form factor: The connector should be able to fit within the available space and form factor constraints of the electronic device.
It is important to consider these environmental requirements when selecting board-to-board connectors to ensure reliable performance and long lifespan in the specific application.
