Products Description
· Current Rating: 2A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 500V AC
· Contact Resistance: 20mΩ Max
Product Introduction
Applications
· Material handling equipment
· Building and home automation
· Industrial controls
· Robotics
· Medical equipment
· Office equipment
· IoT
Specifications
· Current Rating: 2A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 500V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Gold flash(0.8") Standard
Higher gold available
Tin
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact XHS to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Help to make smaller finished product come true
● Simplify the assembly process of electronic products
● Meet the demands of miniaturizing electronic products
● Could solve critical size requirement problem.
● Simplify manufacturing procedure
● Reduct the production cost
Advantages
● Good materials, all materials meet RoHS, REACH certification
● Perfect quality control from materials to finished products.
● Traceability of Order and raw material
● Systematic lab testing ability
Shenzhen Xuhuasheng Technology Co., Ltd.(XHS) has been devoted to the production and sale of electronic connectors for 10 years, adhering to the belief of quality first and customer first. We are a reliable manufacturer in male headers connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in male headers connectors, welcome you to contact us. Just call or send email to us to get professional support, believe that XHS will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
Q: How is the quality of your connectors?
A: The company has established a high-standard quality supervision system, and has passed the IATF16949 quality management system certification of the automotive industry and the ISO-9001:2008 quality system management system. Products from raw materials to final products will go through IQC, FAI, IPQC, OQC several times to ensure product quality. All raw materials are also certified by ROHS, REACH and UL.
Q: What is the soldering temperature resistance of the product?
A: PBT soldering temperature resistance is 230℃, PA6T 260℃ and LCP 280℃.
Q: What are the forms of CAP for SMT products?
A: The default tape and reel packaging comes with a cap. And there are the following types of caps: mylar, plastic cap and metal cap. Some customers do not need a cap and need to be notified in advance.
Q: What are the shipping options?
A: Generally, we ship by international express such as FEDEX, DHL, TNT, UPS, etc., and by sea, air, or truck is aslo available.
