Products Description
· Current Rating: 2A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 500V AC
· Contact Resistance: 20mΩ Max
Product Introduction
Applications
· Industrial automation
· Medical equipment
· Office equipment
· Home appliances
· Audio
· Security equipment
· Monitor
Specifications
· Current Rating: 2A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 500V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Gold flash(0.8") Standard
Higher gold available
Tin
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact XHS to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Help to make smaller finished product come true
● Simplify the assembly process of electronic products
● Meet the demands of miniaturizing electronic products
● Low cost multiple pitches connectors per your application requirements.
Advantages
● Integrated production and assembly pocess can save your time to market and increase your profit.
● Well package, protect products during long international transit
● Free sample
● Perfect quality control from materials to finished products.
● Traceability of Order and raw material
● Systematic lab testing ability
Shenzhen Xuhuasheng Technology Co., Ltd.(XHS) has been devoted to the production and sale of electronic connectors for 10 years, adhering to the belief of quality first and customer first. We are a reliable manufacturer in female to male header pins connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in female to male header pins connectors, welcome you to contact us. Just call or send email to us to get professional support, believe that XHS will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
Q: What products do you produce?
A: Products include board-to-board connectors of pin headers, female headers, box header; board-to-wire connectors of wafer, FPC,RJ, and various customized wiring harnesses.
Q: What is the soldering temperature for XHS's connectors?
A: PBT soldering temperature resistance is 230℃, PA6T 260℃ and LCP 280℃
Q: What shipping options are available?
A: Yes, normally we adopt international courier methods like DHL, TNT, FEDEX, UPS. Air shippment and sea shippment is also available.
