Products Description
· Current Rating: 1A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 300V AC
· Contact Resistance: 20mΩ Max
Product Introduction
Applications
· Instrumentation and test equipment
· Audio
· Video
· Scanner
· IoT
· Security equipment
· Monitor
Specifications
· Current Rating: 1A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 300V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Gold flash(0.8") Standard
Higher gold available
Tin
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact XHS to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Simplify the assembly process of electronic products
● More convenient to replace and upgrade connectors
● Easy to replace old connectors, save more time and labor cost.
● Improve design flexibility
● Ensure the smooth continuous and reliable flow of current
● Stable Connection
● Meet the demands of miniaturizing electronic products
Advantages
● Mature R&D team
● Skilled and stable staff
● Good before-sales and after-sales service
● Well package, protect products during long international transit
● Mechanized production, stable quality
● Complete product range, full pitch series
Shenzhen Xuhuasheng Technology Co., Ltd.(XHS) has been devoted to the production and sale of electronic connectors for 16 years, adhering to the belief of quality first and customer first. We are a reliable manufacturer in board to board connector with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in board to board connector, welcome you to contact us. Just call or send email to us to get professional support, believe that XHS will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
Q: Will I pay duty tax on an international order?
A: Yes, duty tax is charged by your government when you order something outside of your country, not by our company.
Q: What is the shipping charge for international packages?
A: For any international package, if you have questions about shipping costs, contact our customer service department. You will need to provide your shipping address so we can better help you with shipping charges.
Q: What could cause a shipping delay?
A: During the holiday season, shipping delivery may be longer than normal.
