Products Description
· Current Rating: 1A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 300V AC
· Contact Resistance: 20mΩ Max
Product Introduction
Applications
· Medical equipment
· Office equipment
· Home appliances
· Servo drives
· Material handling equipment
· Building and home automation
· Industrial controls
Specifications
· Current Rating: 1A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 300V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Gold flash(0.8") Standard
Higher gold available
Tin
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact XHS to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Help to make smaller finished product come true
● Simplify the assembly process of electronic products
● More convenient to replace and upgrade connectors
● Easy to replace old connectors, save more time and labor cost.
Advantages
● Free sample
● Perfect quality control from materials to finished products.
● Traceability of Order and raw material
● Systematic lab testing ability
Shenzhen Xuhuasheng Technology Co., Ltd.(XHS) has been devoted to the production and sale of electronic connectors for 16 years, adhering to the belief of quality first and customer first. We are a reliable manufacturer in male to male pin header connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in male to male pin header connectors, welcome you to contact us. Just call or send email to us to get professional support, believe that are will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
Q: What is the shipping cutoff time?
A: All our products are new produced, there is no exact shipping cutoff time. Normally we all could deliver out on time.
Q: How to buy your products?
A: Please contact our company's sales staff directly to confirm the demand and make a purchase. We'll happily look after all your requirements.
Q: What materials are used in your products
A: Most of the products are made of PA6T plastic, and a few of them are made of PBT. Some also use LCP, see the corresponding drawings for details.
