14pin 26pin 36pin 50pin PCB Vertical SCSI MDR Connector, 1.27mm pitch PCB Straight CN Type Female SCSI Connector
Quick Details
Type: Terminal Connectors, Contact Connector, SCSI Connector
Application: servo and automation devices
Interface Type: Centronics
Packaging: Tray
Supplier Type: Original manufacturer
Place of Origin: Guangdong, China
Color: Black
Material: PBT
Brand Name: PCB SCSI Connector
Number of Positions: 14pin 26pin 50pin
Pitch: 1.27mm, 1.27mm pitch connector
Number of Rows: 2
Mounting Type: PCB
Center Contact Plating: Gold plating
Connector Line: SCSI Connector
No. of Contacts: 14pin 26pin 36pin 50pin
Gender: Female Connector
Connector Type: PCB Right Angle Connector
Contact material: Phosphorous Bronze
Contact Plating: Gold plating (1u",3u",5u",10u",15u")
Insulation Color: Black
Insulation Material: PBT
Shell material: Nickel plated
Packaging & Delivery
Selling Units: Single item
Single package size: 9X2X2 cm
Single gross weight: 0.100 kg
Replacement to Amphenol Centronics 36pin Solder Connector 57-60360, 50pol Female SCSI Connector DDK 57-60500 Connector with Solder Fitting
The Centronics connector has a plastic bar in the center of the connector body that holds the contact pins. The body of the connector is often black or blue in color.
The Centronics 50pin connector is arranged in two rows of pins each with 25 contacts, it is most often used by older SCSI-1 devices (scanners, storage devices, etc.).The Centronics 36pin connector is arranged in two rows of pins, each with 18 contacts. The connector is held in place by bail locks. The 36pin connector is often used for parallel applications, especially for printers.
FAQ
Q: When can I get the quotation?
A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us so that we will regard your inquiry priority.
Q: How can I get a sample to check your quality?
A: After price confirmation, you can require for samples to check our quality.
If you need the samples, we would like to send sample from our Chinese factory.
Q: What kind of files do you accept for printing?
A: PDF, STEP.
Q: Can you do the design for us?
A: Yes. We have a professional team having rich experience in design and manufacturing.
Q: How long can I expect to get the sample?
A: 3-5 working days for samples.
