Products Description
· Current Rating: 3A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 600V AC
· Contact Resistance: 20mΩ Max
Product Introduction
Applications
· Power systems
· IoT
· Home appliances
· Servo drives
· Security equipment
· Monitor
· LED Screen
Specifications
· Current Rating: 3A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 600V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Gold flash(0.8") Standard
Higher gold available
Tin
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact XHS to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Help to make smaller finished product come true
● Simplify the assembly process of electronic products
● More convenient to replace and upgrade connectors
● Easy to replace old connectors, save more time and labor cost.
Advantages
● Well package, protect products during long international transit
● Mechanized production, stable quality
● Complete product range, full pitch series
● Good materials, all materials meet RoHS, REACH certification
Shenzhen Xuhuasheng Technology Co., Ltd.(XHS) has been devoted to the production and sale of electronic connectors for 10 years, adhering to the belief of quality first and customer first. We are a reliable manufacturer in Interconnects Rectangular Connectors Board Spacers connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in Interconnects Rectangular Connectors Board Spacers connectors, welcome you to contact us. Just call or send email to us to get professional support, believe that XHS will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
Q: Can I make changes to an order which I already placed?
A: Can be modified within a week after order confirmed.
Q: What is the insulation resistance for XHS's connectors?
A: It's upon to different pitch, please check the drawing to get the specific informaiton.
Q: What is the soldering temperature for XHS's connectors?
A: PBT soldering temperature resistance is 230℃, PA6T 260℃ and LCP 280℃.
