Products Description
· Current Rating: 3A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 600V AC
· Contact Resistance: 20mΩ Max
Product Introduction
Applications
· Power systems
· IoT
· Industrial controls
· Audio
· Video
· Scanner
· LED Screen
Specifications
· Current Rating: 3A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 600V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Gold flash(0.8") Standard
Higher gold available
Tin
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact XHS to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Good impact resistance
● Easy to use
● Low insertion force
● Low space requirements
Advantages
● Low maintenance cost, can save a lot of manpower and material resources.
● It can provide good ground isolation to prevent signal interference.
● Professional consultancy & technical support
● Various transporation method
Shenzhen Xuhuasheng Technology Co., Ltd.(XHS) has been devoted to the production and sale of electronic connectors for 10 years, adhering to the belief of quality first and customer first. We are a reliable manufacturer in male connector pins connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in male connector pins connectors, welcome you to contact us. Just call or send email to us to get professional support, believe that XHS will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
Q: What is the insulation resistance for XHS's connectors?
A: It's upon to different pitch, please check the drawing to get the specific informaiton.
Q: How much dielectric withstanding voltage is for XHS's connectors?
A: The circular and DIN connectors withstand 1000 V (AC) at 50 or 60 Hz for 60 seconds with no flashover or breakdown between every two contacts or between every contact and outer contour of the housing.
Q: What material are XHS's connectors made of?
A: XHS's connectors are made of rugged glass-filled PBT and PA.
