Products Description
· Current Rating: 2A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 500V AC
· Contact Resistance: 20mΩ Max
Product Introduction
Applications
· Power systems
· IoT
· Security equipment
· Monitor
· Home appliances
· Stereo Amplifier
· LED Screen
Specifications
· Current Rating: 2A Max
· Insulation Resistance: 1000MΩ Min
· Dielectric Withstanding: 500V AC
· Contact Resistance: 20mΩ Max
· Operating Temperature: -40°C - +105°C
· Solderability: Reflow capable up to 260°C
Materials
· Plating: Gold flash(0.8") Standard
Higher gold available
Tin
· Contact Material: Cooper Alloy
· Housing Material: High-temperature Thermoplastic
· Environmental: UL94 V0
Others
· 2D drawing
· Contact XHS to get 3D file
· RoHS & REACH compliant
· UL compliant
Features
● Light weight and flexible.
● Compachness of electronic products
● Easy assembling and low production cost
● Simple and clean internal design
Advantages
● Complete product range, full pitch series
● Good materials, all materials meet RoHS, REACH certification
● Both small and large orders are acceptable
● Fast delivery time of average 4 weeks
Shenzhen Xuhuasheng Technology Co., Ltd.(XHS) has been devoted to the production and sale of electronic connectors for 10 years, adhering to the belief of quality first and customer first. We are a reliable manufacturer in box header with latch connectors with high quality and best price. We focus on providing high value products to our customers including male header, female header, box header, wafer, FPC, RJ and wiring harness. Any demand in box header with latch connectors, welcome you to contact us. Just call or send email to us to get professional support, believe that XHS will be your best business partner!
Packaging and Shipping
Inspection Equipment
Our Certificate
Q＆A
Q: What materials are used in your products?
A: Most of the products are made of PA6T plastic, and a few of them are made of PBT. Some also use LCP, see the corresponding drawings for details.
Q: What are the storage requirements?
A: Temperature: 5℃-30℃ and Humidity: ≤65%.
Q: What are the forms of CAP for SMT products?
A: The default tape and reel packaging comes with a cap. And there are the following types of caps: mylar, plastic cap and metal cap. Some customers do not need a cap and need to be notified in advance.
