Product Overview
XHSConn's 5.08mm pin header is a single row type with dual plastic. It helps with signal and power transfer on boards. The product uses copper alloy contacts. It has high-temp plastic housing. It works for spaces in electronics. Applications include monitors, inverters, and LED screens. The connector has dual plastic for strength. It makes assembly easy. As a China supplier, we offer custom sizes. The product meets RoHS standards.
Our connector differs from others. It has gold or tin plating options. This reduces resistance. It suits high-speed data. We see many electronics need strong connectors. Copper alloy gives good conductivity. Plastic housing adds insulation. This setup fits modern gadgets.
Specs Summary
|
Current Max |
5A highest |
|
Insulation Resistance |
1000MΩ lowest |
|
Voltage Withstand |
1000V AC |
|
Contact Resistance |
20mΩ highest |
|
Temperature Range |
-25°C to +85°C |
|
Plating Type |
Tin (standard) |
|
Contact Material |
Copper alloy |
|
Housing Material |
High-temp plastic (UL94 V0) |
|
Standard |
RoHS & REAC |
|
Pitch Size |
5.08mm |
|
Type |
Single row dual plastic |
Main Benefits
- Reliable transfer: Low resistance keeps signals steady. It suits fast data needs.
- Simple install: Dual plastic type saves time on boards. It cuts production steps.
- Strong protection: Housing resists heat and shakes. It works in rough spots.
- Cost saving: Light weight lowers material use. It reduces overall expense.
- Flexible fit: Easy match with current systems. We support changes for your needs.
Use Areas
The connector fits monitors for stable power. It works in inverters for space saving. It suits LED screens for light weight. We see questions on how to choose pitch. 5.08mm works for power boards. Smaller pitch suits signal needs.
Real Industry Case: Industrial Electronics Integration
In 2026, we worked with a factory company. They used our 5.08mm pin header for control panels. The problem was heat in factories. It caused connection issues.
We optimized the connector with gold plating. This added strength. It ensured stable 5A transmission in -20°C to +80°C range. Tests showed contact resistance under 15mΩ. Heat rate was 98%.
The panel had 20% less failures after launch. Efficiency rose 15%. The company said dual plastic design saved board space. It cut assembly time by 18%. This case showed our product's role in factories. It helped the client make better panels. If you have like needs, contact us for samples or plans.
